Rotary Solenoid, 24V DC, 95 degree Rotation Angle - 90126
$549.00
Kuhnke
Read more
$238.00
Part Number: 51672 | 24V DC | Function: Spring return| 95° Rotation Angle | Type Number D 39-BOR -F-DS9420-24VDC 100%ED
Unable to find your required voltage or performance parameters?
Contact us at Solenoid Ninja to find the most effective solution for your needs.
Technical Details
| Supply voltage: | 24V DC |
| Function: | Spring return |
| Duty cycle: | 100% |
| Power draw: | 6W |
| Rotation angle: | 95° |
| Direction of rotation: | Clockwise rotation |
| Torque: | Start: 0.18 Ncm End: 1.2 Ncm |
| Connection: | Wire leads |
| IP class: | IP 00 |
| Switching time: | 2.5 - 12ms |
Description
Part Number: 51672 | 24V DC | Function: Spring return| 95° Rotation Angle | Type Number D 39-BOR -F-DS9420-24VDC 100%ED
Unable to find your required voltage or performance parameters?
Contact us at Solenoid Ninja to find the most effective solution for your needs.
Technical Details
| Supply voltage: | 24V DC |
| Function: | Spring return |
| Duty cycle: | 100% |
| Power draw: | 6W |
| Rotation angle: | 95° |
| Direction of rotation: | Clockwise rotation |
| Torque: | Start: 0.18 Ncm End: 1.2 Ncm |
| Connection: | Wire leads |
| IP class: | IP 00 |
| Switching time: | 2.5 - 12ms |
Reviews (0)
Be the first to write a review
Be the first to write a review
Additional info
SKU:
51672
Availability:
Lead time 6- 8 weeks
Weight:
0.33 LBS
