AC Frame Solenoid, 24V AC, 10mm - 50E00128A02V01

Binder Magnete $58.25

Part Number 50E00128A02V01| Push-pull type solenoid | 24V AC/ 50Hz | 15% Duty Cycle | 10mm Stroke | 73.5W | Apparent Power 96VA | Type Number 50E00128A02

Are you looking for a Frame Solenoid with 24V AC/ 50Hz that provides 10mm of stroke? Solenoid Ninja has the perfect solution for you! Linear Solenoids from Binder Magnete are used in the machine building industry for various applications. Additional features of our high force frame solenoid are high flexibility, high forces and a small footprint - due to our solid frame design.

Unable to find your required voltage or performance perimeters?
Contact us at Solenoid Ninja to find the most effective solution for your needs.

Technical Details

Operation: Push-pull type solenoid
Supply voltage: 24V AC / 50Hz
Duty cycle: 15%
Power Draw: 73.5W
Stroke: 10mm
Apparent Power: 96VA
Connection: Leads 6"
IP class: IP 00
Insulation class: E





































Downloads





Read more
Add to wishlist

Description

Part Number 50E00128A02V01| Push-pull type solenoid | 24V AC/ 50Hz | 15% Duty Cycle | 10mm Stroke | 73.5W | Apparent Power 96VA | Type Number 50E00128A02

Are you looking for a Frame Solenoid with 24V AC/ 50Hz that provides 10mm of stroke? Solenoid Ninja has the perfect solution for you! Linear Solenoids from Binder Magnete are used in the machine building industry for various applications. Additional features of our high force frame solenoid are high flexibility, high forces and a small footprint - due to our solid frame design.

Unable to find your required voltage or performance perimeters?
Contact us at Solenoid Ninja to find the most effective solution for your needs.

Technical Details

Operation: Push-pull type solenoid
Supply voltage: 24V AC / 50Hz
Duty cycle: 15%
Power Draw: 73.5W
Stroke: 10mm
Apparent Power: 96VA
Connection: Leads 6"
IP class: IP 00
Insulation class: E





































Downloads





Reviews (0)

Be the first to write a review

Additional info

SKU: 50E00128A02V01
Availability: Lead time 12 weeks
Weight: 0.55 LBS
